HVAC Air Conditioning Copper Insulation Tube
MPa Classfication: High Pressure Piping
Material: Copper Alloy
Standard: ASTM, ASTM B88, ASTM B837, ASTM B306, ASTM B883
Diameter: 1/4-3/4
Medium: Gas
Basic Info.
Product Description
1.full copper pipe
2.the wall thickness and the length of the copper pipe can be customized
3.the copper nut can be customized
4.the insulation coating can be customized
5.smooth flaring
6.short production time
7.small order is allowed
We are one professional manufacturer of 20m/50m Pre-insulated refrigerant copper twin pipe in China,exported to many countries,like USA,France,Germany,UAE,Jordan,Turkey,Brazil etc.We will offer you professional,good and competitive price.
Production Details
Chemical Composition & Mechanical Property-ASTM B280 Copper
Copper Alloy | Chemical Composition | Temper | Grain Size | Cleanness mg/m3 | Eddy Current | Tensile Strength MPa | Elongation | |
TP2 | Cu+Ag | Phosphorus | O60 | 0.015-0.060 | <=25 | <=5 point/coil | >=205 | >=43 |
>=99.90 | 0.015-0.040 | |||||||
Insulation Pipes What We Can Do
Material | Color | Size | Wall Thickness | Popular Wall Thickness |
White Embossed PE | Pink/White/Gray/Blue | 1/4~1-1/8 | 6mm-25.4mm | 9mm/10mm/13mm/25.4mm |
Black Rubber | Black/Red/Blue | 1/4~1-1/8 | 6mm-25.4mm | 9mm/10mm/13mm/25.4mm |
Gray Foam | Gray/Red | 1/4~1-1/8 | 6mm-25.4mm | 9mm/10mm/13mm/25.4mm |
Twin Pair Coil Set
Pair Coil Size | Wall Thickness Of Copper | Coil Length | Packing |
1/4+3/8 | 0.65-1.0 | 3m-15m | Carton Box/Bag |
1/4+1/2 | 0.65-1.0 | 3m-15m | Carton Box/Bag |
1/4+5/8 | 0.65-1.0 | 3m-15m | Carton Box/Bag |
3/8+5/8 | 0.65-1.0 | 3m-15m | Carton Box/Bag |
3/8+3/4 | 0.65-1.0 | 3m-15m | Carton Box/Bag |
Single Copper Line
Pair Coil Size | Wall Thickness Of Copper | Coil Length | Packing |
1/4 | 0.65-1.0 | 3m-50m | Carton Box/Bag |
3/8 | 0.65-1.0 | 3m-50m | Carton Box/Bag |
1/2 | 0.65-1.0 | 3m-50m | Carton Box/Bag |
5/8 | 0.65-1.0 | 3m-50m | Carton Box/Bag |
3/4 | 0.65-1.0 | 3m-50m | Carton Box/Bag |
7/8 | 1.0-1.50 | 3m-50m | Carton Box/Bag |
1-1/8 | 1.20-1.50 | 3m-50m | Carton Box/Bag |
Production process:
Package and shipment:
1) Packed with plastic film,or packed in standard export carton.
2)Can packed as customer's requirement
3)Can shipped by sea freight,Air freight,express, cheapest way is sea freigh.
Factory picture:
Related products:
Our company:
